Features:
1.Adopt constant power water-cooled frequency spindle, high speed, low noise and long life.
2.Three axises adopt precise ball screw transmission, reasonable structure, stable performance, good weight bearing ability.
3.This machine is mini machine, low price, high performance, especially suitable for home and small enterprises,institutions to do processing.
4.Users can assemble electric spindle and driving control system according to their own needs.
Application:
Is especially designed for rosewood furniture, classic furniture and relief engraving. Also be Appliable for advertising, arts&crafts, model, presents, wood construction architecture model, schools, enterprise and institutions etc.
Applicable material:
Wood, plastic, jade, soft metal materials
Technical Parameter:
Model | SM-3030 |
X Y working area | 300*300mm |
Z working area | Max 60mm |
Max. Feeding height: | 60mm |
Max. working speed | 0 - 4,000mm/min |
Max. speed | 0 - 4,000mm/min |
Repositioning accuracy | 0.05mm |
Table structure | Aluminium T-slot |
Transmision | Ballscrew |
Command language | G-code, u00,mmg,plt |
Max. power consumption: | 1.2KW |
Spindle speed | 0-24000rpm/min |
Manner of receiving data: | USB or PCI |
Drive system | stepper |
Table size | 370mm * 440mm |
Working delicacy | 0.015mm |
Software: | Type3 |
Spindle: | 0.8KW variable speed, water cooled motor |
Working voltage: | AC 220V, 50-60Hz |
Weight: | 57kg |
Delivery: within 15 days after receiving deposit
Payment: Bank Transfer
Warranty: 1 Year
Package: fumigation-free wooden box
